M5 / Merlin Series Main Lighting Distribution Board Grey Color Metal Base And Plastic Cover

Place of Origin : China

Brand Name : QK

Certification : RoHS, CE, UL,CCC,ISO9001

MOQ : 1 Piece

Payment Terms : T/T,L/C,Western Union

Price : Negotiation

Packaging Details : Regular export packing and can accept customized

Supply Ability : 1000 Pieces/month

Model Number : Merlin 18#

Delivery Time : 5-8 work days

Paint Finish : Epoxy Polyester Coating

Color : Grey

OEM : Offered

Material : Plastic,Panel made of iron

Protection Level : IP66

Lock : Available On Request

Contact Now

6 Way M5 / Merlin Series Distribution BoxF

Advantage

1. Rain proof

2. High temperature resistance

3. Fire prevention

4. Heat dissipation hole

Brief Description

This distribution box applies to terminal of AC 50Hz(or 60Hz), rated operated voltage up to 400V and rated current up to 63A, equipped with various modular electric for functions of electric energy distribution, control, ( short circuit, overload, earth leakage, over-voltage) protection, signal, measurement of terminal electric appliance.

Structure

Symmetric base enclosure: solid enclosure can be embedded into thinner wall; knockouts of various sizes on four sides of box;

Characteristic

Product name	Distribution box
Material	Sheet Steel
OEM	Offered
Package	1 Piece Per Carton
Certification	CE,CCC,ROHS,TUS
Paint Finish	Epoxy Polyester Coating
Lock	Available On Request
Thckness	1.0mm
Color	Ral7035
Accessories	Wall Mount Brackets To Be Offered Seperately

ZheJiang GuoKong Co.,Ltd with know-how, expertise, and rich experience, we are on the way to do better and better.We according to customer needs, provides distribution box with kinds of size.we have means and materials to create and product wiring solutions for both demestic and ourseas customers.

We provide various sizes of distribution box.

We provide various thickness of distribution box.

If you need specified product,please consult us.

12 way eletrical power M5 series industrial distribution box

Standard	Over Dimdension
Standard	Height(mm)	Width(mm)	Depth(mm)	Thickness(mm)
6#	200	183	85	1.0
9#	200	238	85	1.0
12#	200	293	85	1.0
15#	200	347	85	1.0
18#	200	400	85	1.0
21#	200	455	85	1.0
24#	382	293	85	1.0
30#	410	347	85	1.0
36#	412	400	85	1.0

M5 / Merlin Series Main Lighting Distribution Board Grey Color Metal Base And Plastic Cover
